UNI-T UT526 Electrical Insulation Tester1000V 500MΩ RCD Test Continuity VAC/DC
UNI-T UT526 Electrical Insulation Tester1000V 500MΩ RCD Test Continuity VAC/DC
UT526 are newly designed digital multi-functional testing meters adopted large-scale integrated analog/digital circuit and Micro-processing chip. UT526 are highly accurate, reliable, and user-friendly. They are your ideal tools to test the parameters of residual current device (RCD), earth resistance, insulation resistance, DC and AC voltage.UT520 series complies with the over voltage standard (CAT III 600V).
| Specifications | Range | Best Accuracy | |
| Model | UT526 | ||
| Insulation Resistance(Ω) | Test Voltage | 250V/500V/1000V | ±10% |
| 250V | 0.05MΩ～200MΩ | ±(5%+5) | |
| 500V | 0.05MΩ～300MΩ | ±(5%+5) | |
| 1000V | 0.05MΩ～500MΩ | ±(5%+5) | |
| Test Current | 250V(R=250KΩ) 1mA | ±10% | |
| 500V(R=500KΩ) 1mA | ±10% | ||
| 1000V(R=1MΩ) 1mA | ±10% | ||
| Short Circuit Current: | <2mA | √ | |
| RCD | Operational Voltage(Freq.) | 220V(45Hz--65Hz) | ±10% |
| Test Current | 10mA/30mA/100mA/300mA | 0～10% | |
| Trip Time | 0ms～2000ms，1Δn Genetal（10mA） | ±(5%+2) | |
| 0ms～500ms，1Δn Genetal（300mA） | |||
| 0ms～300ms，1Δn Genetal（100mA，300mA） | |||
| Low Resistance Continuity(Ω) | Range | 0.00Ω~2000Ω | ±(2%+5) |
| Test Voltage | Around 5.0V | √ | |
| Test Current | >200mA(R<2Ω) | √ | |
| Voltage Mesurement(V) | DC Voltage | 0～440V | ±(2%+3) |
| AC Voltage | 0～440V | ±(2%+3) | |
| Frequency (Reference Only) | √ | ||
| Features | |||
| Display Count | 9999 | ||
| Manual Range | √ | ||
| Phase Switch(RCD) | 0°and 180° | √ | |
| Low Battery Indication | √ | ||
| Automatically Selects DCV or ACV | √ | ||
| Red Warning Lights | √ | ||
| General Characteristic | |||
| Power | 1.5V Alkaline Batteries（LR6）×6(Battery Not Include) | ||
| LCD Size | 71mm X 34mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 380g | ||
| Product Size | 160mm X 100mm X 71mm | ||
| Standard Accessories | Test Lead,Batteries，Carrying Bag，Alligator Clip | ||
| Standard Individual Packing | Gift Box，English Manual | ||
